干式蒸发器(双机组)技术参数：
| 型号 MODELS |
制冷量 | 进出口直径 CONNECTION(INCHES) | 重量（Kg） WEIGHT |
||||
| Kw | RT | G1 | G2 | G3 | G4 | ||
| RE17×2 | 17.6×17.6 | 5+5 | 7/8 | 5/8 | 7/8 | 5/8 | 89 |
| RE28×2 | 28.1×28.1 | 8+8 | 1-1/8 | 5/8 | 1-1/8 | 5/8 | 105 |
| RE35×2 | 35.2×35.2 | 10+10 | 1-3/8 | 5/8 | 1-3/8 | 5/8 | 120 |
| RE52×2 | 52.8×52.8 | 15+15 | 1-5/8 | 7/8 | 1-5/8 | 7/8 | 185 |
| RE70×2 | 70.3×70.3 | 20+02 | 2-1/8 | 7/8 | 2-1/8 | 7/8 | 212 |
| RE87×2 | 87.9×87.9 | 25+25 | 2-1/8 | 1-1/8 | 2-1/8 | 1-1/8 | 265 |
| RE105×2 | 105.5×105.5 | 30+30 | 2-1/8 | 1-3/8 | 2-1/8 | 1-3/8 | 290 |
| RE123×2 | 123×123 | 35+35 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 327 |
| RE140×2 | 140.7×140.7 | 40+40 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 245 |
| RE158×2 | 158.3×158.3 | 45+45 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 441 |
| RE175×2 | 175.9×175.9 | 50+50 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 523 |
| RE193×2 | 193.4×193.4 | 55+55 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 539 |
| RE211×2 | 211×211 | 60+60 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 602 |
| RE228×2 | 228.6×228.6 | 65+65 | 2-5/8 | 1-3/8 | 2-5/8 | 1-3/8 | 620 |
| RE246×2 | 246.2×246.2 | 70+70 | 2-5/8 | 1-5/8 | 2-5/8 | 1-5/8 | 637 |
| RE263×2 | 263.8×263.8 | 75+75 | 2-5/8 | 1-5/8 | 2-5/8 | 1-5/8 | 652 |
